TSC series speed belt scale belt scale
The speed regulating belt scale produced by Jiangsu Zhongkuang Cement Complete Equipment Co., Ltd. is mainly composed of a fixed frame and a movable body, and is connected as a whole by dust-proof bearing, rod end tension bearing and "S" type tension sensor. The measurement error caused by the quality problem of the "ten" reed and the conveyor belt is overcome, and the measurement degree of the material is greatly improved. It can be widely used in the measurement and batching process of bulk and block materials in building materials, metallurgy, chemical industry, grain and oil industries.
TSC series speed belt scale-main technical parameters table:
Model | Parameters | Bandwidth (mm) | Metering accuracy | Upper limit of belt speed m/s | Upper limit of conveying capacity m3/h | Motor power Kw |
TSC500 | 500 | ±0.5% | 0.126 | 28 | 0.75 |
TSC650 | 650 | 0.126 | 40 | 0.75 | |
TSC800 | 800 | 0.132 | 55 | 1.1 | |
TSC1000 | 1000 | 0.132 | 85 | 1.5 | |
TSC1200 | 1200 | 0.132 | 110 | 2.2 |
