QTLV-0.1 pneumatic push rod flat gate valve
Ⅰ. Purpose
QTLV-0.1 pneumatic push rod flat gate valve is a product of Jiangsu ChinaMining which is improved based on traditional mechanism, with advanced technology and reliable quality. Widely used in pipelines for dust material flow control in industries such as metallurgy, mining and building materials, it is ideal equipment for controlling quick opening and closing requirements.
Ⅱ. Working principle
QTLV-0.1 pneumatic push rod flat gate valve mainly consists of components such as frame, gate plate and cylinder. During operation, due to the pressure change of the gas in the cylinder, the piston rod drives the ram to move back and forth in a horizontal direction, thereby achieving the purpose of opening and closing the valve.
Ⅲ. Main performance parameters
（MPa） Nominal pressure | 0.1~0.6 |
（℃） Working temperature | ≤150 |
（T/h）Feeding capacity | 粉尘物料 Dust materials |
